Alternator Rebuild Kit for Audi S6 2.2L Turbo (1995–1997) 0123515012, 0123515024 - 13624RK-A

Need to rebuild your vehicle's alternator? This premium rebuild component kit is engineered to meet or exceed original factory specs, ensuring a perfect fit and long-lasting charging performance.

🚘 Vehicle Application Details

• Audi: S6 (1995-1997 L5 2.2L)

🔍 Cross-Reference Alternator Assemblies (Fits These Units)

• Audi / Volkswagen OE: 046-903-015F, 046-903-015FX, 059-903-015, 059-903-015X
• Bosch OE & Reman: 0123510028, 0123515012, 0123515024, AL0720X, 0 986 039 690, 0 986 044 530
• Other References: Excel 10376, Hollander 58649, Lester 13624, PIC 220-328, PIC 220-328A

📐 Component-Specific Technical Data

⚡ Voltage Regulator Specs

• Technical Specifications: 12 Volt, A-Circuit, 14.3 Vset
• Design: For Bosch Alternators
• Replaces OEM: Audi / Volkswagen 028903803E, 028903803G | Bosch 1197311511, 1987237078 | Marelli 940038024
• Aftermarket Crossovers: IB511, W080-23, 230-24064, VRB235, MFVR00410, BO-1783, 80201186

⚡ Drive End Bearing (Front) Specs

• Industry Number: 55224 / B17-99D
• Dimensions: 17mm ID x 52mm OD x 17mm W
• Interchange Numbers: Bosch 1120905012, 1120905054, 1120905055, 1120905084, 1120905089, 1120905094, 1120905510, 1120905520, 1120905531, F00M990414, F00M990417, F00M990434, 10-3043-4W

⚡ Rotor SRE Bearing (Rear) Specs

• Industry Number: 54000 / 6203
• Dimensions: 17mm ID x 40mm OD x 12mm W
• Interchange Numbers: Bosch 1120905013, 1120905041, 1120905080, 1120905083, 1120905091, 1120905525, 1120905534, 1900905203, 1900905209, 1900905227, 1900905271, 1900905273, 1900905277, 1900905281, 1900905384, 6-203-4W

⚡ Bearing Tolerance Ring Specs

• Technical Specifications: For use with 6203 bearing
• Dimensions: 40mm ID x 43mm OD x 16.5mm Overall Length
• Replaces OEM: Bosch 1120591076, 1120591103 | Volvo 9130106, 9130106-9
• Interchange Numbers: 46-91552, 130-07016, W110-39, 5652

⚡ Slip Ring Specs

• Dimensions: 7.1mm ID x 16.1mm OD
• Replaces OEM: Bosch 1124303007, F00M143019
• Interchange Numbers: 28-91852, 313-24002, 7120202
